A diagonal view of the Intermediate HRG in an HR2 enclosure
An open panel view of the Intermediate HRG in an HR2 enclosure
  • Open and shortened monitoring of neutral grounding resistor through
    • Resistance monitoring with passive and active measurement methods
    • Current and voltage monitoring
    • Functional even when de-energized
  • Monitoring of current transformer
  • AC and DC current monitoring
  • Built in pulsing for handheld ground fault tracing
  • Advanced harmonics analysis and filtering – no nuisance tripping
  • Individually adjustable ground fault indication values
  • Built in test and reset capability
  • Password protection
  • Configurable in English, French, Spanish, and German

Intermediate HRG

Our intermediate model HRG brings the newest technology of 2018 together to create the most advanced level of protection at a reasonable price. With integrated resistor monitoring, pulsing, harmonics filtering, communications, and data logging, this system is the best solution for managing ground faults.

A conveniently designed enclosure allows for wall-mounting or floor-mounting depending on your preferences and available space. The front panel comes with the main HMI directly mounted, accessible in four different languages. Authorized repair personnel can directly interact with and control the entire system from this HMI.

Quote Request
  • A screenshot of the data logging interface in the communications dashboard
  • The home page main overview of the communications dashboard
  • An overview of all devices connected to the communications dashboard and their current measured values
  • Modern HTML5 web interface: device alarm status and readings, accessible from any computer or phone
  • Data logging: memory for up to 1000 events
  • Modbus/TCP third party device support
  • Connects to any standard ethernet network

Configuration Options

Main Specifications

Voltage

Please provide the line to neutral (L/N) voltage. Standard ratings are 277V (480V L/L), 347V (600V L/L), and 2400V (4160V L/L).

Current

The ground fault current. Typical ratings are 5 Amps or 10 Amps. A multi-tapped resistor is also possible, meeting the requirements for multiple ground fault currents at once (e.g. one at 2A, another at 5A, another at 10A).

System Type

A Wye configuration is the standard, when there is a readily available neutral. When there is a Delta configuration, we must create a neutral with the use of a Zig-Zag (Neutral Grounding) transformer. If you select Delta, we can provide a Zig-Zag if we know your system rated kVA and primary voltage.

Control Power

The power supplied for the HRG control panel. We can provide 120VAC or 24VDC depending on your preference, our standard is 120VAC.

Additional Features
  • Strobe Light: any time there is a ground fault a red strobe light will alert all staff
  • Horn:¬†any time there is a ground fault a horn / buzzer will alert all staff
  • Heater: if the environment your HRG will be in is subject to cold temperatures, condensation can begin to accumulate and potentially damage parts. A condensation prevention heater can be installed to prevent this.
